Ketchup packing machine

Ketchup packing machine
Ketchup packing machine
Product Code : 58
Product Description

FFS Machine Liquid Filling

The process of measuring, bag-making, filling, sealing, printing, coding and counting can be done automatically.

  • Accurate & Precise Design.
  • Noiseless Performance.
  • Contact parts in Stainless Steel.
  • Durable Mechanical Structure.
  • Low Wear & Tear and maintenance.
  • Economical reliable Solution with High Output.
Technical Specifications

Product Application

Liquid/Paste/Ketchup/Lubrication oil/Shampoo/Gel

Sealing Type

4 Side Seal

Packing Size

1-5 gms, 5-20 gms

Feeding System

Dosage Pump



Main Motor

1/2 H.P. 50 Hz Single phase

Heater Load

150 W - 2pcs / 300 W - 2 pcs


Heat sealable laminate film
Core dia 75 mm / Max outer dia 350 mm

Contact Parts

Stainless Steel

Power Consumption

2 Kw

Machine Dimension

L. 1000 x W. 910 x H. 1560 (mm)

Net Weight

350 Kgs

Optional Attachments (At an extra cost)

Electronic contact coder.
Out feed conveyor S.S. Cladding
